Glazed Polypropylene Felt Liquid Bag Filters

SP-BP Series

SpiroPure SP-BP series liquid bag filters utilize a glazed polypropylene felt filter media to accommodate a variety of applications. The polypropylene felt filter media offers a high solid loading capacity, while the glazed finish reduces the chance of migration.
  • Filter has a high dirt-holding capacity for critical applications such as corrosive fluids, including acids, alkalis, oils, and organic solvents
  • Available in sizes: #1, #2, #3, and #4
  • Available nominal filtration ratings of: 1, 5, 10, 25, 50, 100, and 200 microns
  • All SpiroPure polypropylene felt bag filters have a max temperature rating of 176°F
buy onlineSpecifications Sheet
Filter Details Chart
  Model Number Nominal Micron Rating Temperature Rating Case Quantity Case Dimensions Case Weight

#1

SP-BP-1-1
SP-BP-1-5
SP-BP-1-10
SP-BP-1-25
SP-BP-1-50
SP-BP-1-100
SP-BP-1-200

1 micron
5 micron
10 micron
25 micron
50 micron
100 micron
200 micron

< 176°F (80°C)

40

23.5” x 18” x 12”

15 lbs

#2

SP-BP-2-1
SP-BP-2-5
SP-BP-2-10
SP-BP-2-25
SP-BP-2-50
SP-BP-2-100
SP-BP-2-200

1 micron
5 micron
10 micron
25 micron
50 micron
100 micron
200 micron

< 176°F (80°C)

40

23.5” x 18” x 16”

21 lbs

#3

SP-BP-410-1
SP-BP-410-5
SP-BP-410-10
SP-BP-410-25
SP-BP-410-50
SP-BP-410-100
SP-BP-410-200

1 micron
5 micron
10 micron
25 micron
50 micron
100 micron
200 micron

< 176°F (80°C)

40

18” x 14.5” x 10.5”

6 lbs

#4

SP-BP-420-1
SP-BP-420-5
SP-BP-420-10
SP-BP-420-25
SP-BP-420-50
SP-BP-420-100
SP-BP-420-200

1 micron
5 micron
10 micron
25 micron
50 micron
100 micron
200 micron

< 176°F (80°C)

40

24” x 18” x 12”

11 lbs
Cross Reference Chart
Size Rating SpiroPure Pentek

10"

1 micron
5 micron
10 micron
25 micron
50 micron
100 micron
200 micron

SP-BP-410-1
SP-BP-410-5
SP-BP-410-10
SP-BP-410-25
SP-BP-410-50
SP-BP-410-100
SP-BP-410-200

BP-410-1 / 155383-03
BP-410-5 / 155385-03
BP-410-10 / 155387-03
BP-410-25 / 155389-03
BP-410-50 / 155391-03
BP-410-100 / 155393-03
BP-410-200 / 155395-03

20"

1 micron
5 micron
10 micron
25 micron
50 micron
100 micron
200 micron

SP-BP-420-1
SP-BP-420-5
SP-BP-420-10
SP-BP-420-25
SP-BP-420-50
SP-BP-420-100
SP-BP-420-200

BP-420-1 / 155384-03
BP-420-5 / 155386-03
BP-420-10 / 155388-03
BP-420-25 / 155390-03
BP-420-50 / 155392-03
BP-420-100 / 155394-03
BP-420-200 / 155396-03
